Fun, Tough & Amazing Value

Have It Your Way

Proven Spektrum Electronics

Great Features

Under the hood

The VORTEKS In Action

Specifications

ARRMA Part Number
ARA3205T1
ARA3205ST1
ARA3205ST2
Vehicle Name
1/10 VORTEKS 2WD Stadium Truck RTR, Blue
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Orange
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Purple
SCALE
1/10
1/10
1/10
POWER TYPE
Brushed
Brushed
Brushed
BUILD STATUS
RTR
RTR
RTR
Saleable Part #
ARA3205T1
ARA3205ST1
ARA3205ST2
Horizon Hobby Saleable Part #
ARA3205T1
ARA3205ST1
ARA3205ST2
BUILD CONFIGURATION OPTIONS
Mid Motor
Mid Motor
Mid Motor
DRIVE TYPE
2WD
2WD
2WD
VEHICLE TYPE
Stadium Truck
Stadium Truck
Stadium Truck
SURFACE
Off-road
Off-road
Off-road
LENGTH
456mm / 17.95"
456mm / 17.95"
456mm / 17.95"
WHEELBASE
286mm / 11.26"
286mm / 11.26"
286mm / 11.26"
RIDE HEIGHT
40mm / 1.57"
40mm / 1.57"
40mm / 1.57"
FRONT WIDTH
325mm / 12.8"
325mm / 12.8"
325mm / 12.8"
REAR WIDTH
325mm / 12.8"
325mm / 12.8"
325mm / 12.8"
HEIGHT
170mm / 6.69"
170mm / 6.69"
170mm / 6.69"
NUMBER OF DIFFERENTIALS
1
1
1
WEIGHT (INC. SUPPLIED BATTERY)
-
2.78kg / 6lbs 2oz
2.78kg / 6lbs 2oz
WEIGHT (NO BATTERY)
2.34kg / 5lbs 3oz
-
-
BATTERY RECOMMENDATIONS
8.4v (7 Cell) NiMh Hump Pack or Hardcase 7.4V (2S) Lipo
-
-
WARRANTY LEVEL
2 Year Limited
2 Year Limited
2 Year Limited
ARRMA Part Number
ARA3205T1
ARA3205ST1
ARA3205ST2
Vehicle Name
1/10 VORTEKS 2WD Stadium Truck RTR, Blue
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Orange
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Purple
BODY LENGTH
450mm / 17.72"
450mm / 17.72"
450mm / 17.72"
BODY WIDTH
185mm / 7.28"
185mm / 7.28"
185mm / 7.28"
BODY HEIGHT
110mm / 4.33"
110mm / 4.33"
110mm / 4.33"
FRONT SPRING RATE
0.547N/mm
0.547N/mm
0.547N/mm
REAR SPRING RATE
0.402N/mm
0.402N/mm
0.402N/mm
CAPTURED HINGEPINS
Yes
Yes
Yes
TURNBUCKLES/FIXED LINKS
Fixed Link
Fixed Link
Fixed Link
HARDWARE TYPE
Hex Head
Hex Head
Hex Head
LOCKING DIFFS
No
No
No
DIFFERENTIAL TYPE
Gear
Gear
Gear
STANDARD SHOCK OIL (Viscosity)
F: 500 R:300cSt
F: 500 R:300cSt
F: 500 R:300cSt
STANDARD SHOCK OIL (Type)
Silicone
Silicone
Silicone
STANDARD DIFF OIL (Type)
Grease
Grease
Grease
INTERNAL GEAR RATIO
3.13
3.13
3.13
INTERNAL GEAR MATERIAL
Plastic
Plastic
Plastic
FITTED SPUR SIZE
61Tooth
61Tooth
61Tooth
FITTED SPUR MATERIAL
Plastic
Plastic
Plastic
FITTED PINION GEAR SIZE
13Tooth
13Tooth
13Tooth
FITTED PINION MATERIAL
Metal
Metal
Metal
EXTRA SPEED PINION INCLUDED
No
No
No
PINION AND SPUR TOOTH PITCH
0.8Mod
0.8Mod
0.8Mod
STANDARD FINAL GEAR RATIO
14.68
14.68
14.68
TIRE STANDARD
MT (2.8")
MT (2.8")
MT (2.8")
TIRES INCLUDED
dBoots Dirtrunner ST Front / dBoots Katar Rear
dBoots Dirtrunner ST Front / dBoots Katar Rear
dBoots Dirtrunner ST Front / dBoots Katar Rear
TIRE DIAMETER
115mm / 4.53"
115mm / 4.53"
115mm / 4.53"
TIRE INSERT TYPE
Medium
Medium
Medium
DRIVESHAFT TYPE
UJ Slider
UJ Slider
UJ Slider
WHEEL BEAD DIAMETER
71.5mm / 2.81"
71.5mm / 2.81"
71.5mm / 2.81"
WHEEL HEX SIZE
14mm
14mm
14mm
WHEEL STANDARD
MT (2.8" 14mm hex)
MT (2.8" 14mm hex)
MT (2.8" 14mm hex)
WHEEL COLOR/FINISH
Gunmetal
Gunmetal
Gunmetal
MOUNTED TIRES
Yes
Yes
Yes
TIRE ATTACHMENT METHOD
Glued
Glued
Glued
SERVO HORN MATERIAL
Plastic
Plastic
Plastic
SERVO SPLINE SIZE
25T
25T
25T
BATTERY MAX DIMENSIONS
140x50x35mm / 5.51x1.97x1.38"
140x50x35mm / 5.51x1.97x1.38"
140x50x35mm / 5.51x1.97x1.38"
CHASSIS MATERIAL
Moulded Composite
Moulded Composite
Moulded Composite
TRIMMED BODY
Yes
Yes
Yes
BODY-ON BATTERY ACCESS
Yes
Yes
Yes
BODY PIN RETAINERS
Clipless Mounting System
Clipless Mounting System
Clipless Mounting System
MODEL PRODUCTION YEAR
2024
2024
2024
ARRMA Part Number
ARA3205T1
ARA3205ST1
ARA3205ST2
Vehicle Name
1/10 VORTEKS 2WD Stadium Truck RTR, Blue
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Orange
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Purple
POWER LEVEL
MEGA
MEGA
MEGA
RADIO SYSTEM
Spektrum SLT2
Spektrum SLT2
Spektrum SLT2
2.4Ghz
Yes
Yes
Yes
NUMBER OF RADIO CHANNELS
2
2
2
ESC
Spektrum SLT 2-IN-1 40A
Spektrum SLT 2-IN-1 40A
Spektrum SLT 2-IN-1 40A
WATERPROOF ELECTRONICS
Yes
Yes
Yes
ESC CONNECTOR TYPE
IC3
IC3
IC3
MOTOR
ARRMA 14T Brushed
ARRMA 14T Brushed
ARRMA 14T Brushed
MAXIMUM MOTOR SIZE
550
550
550
SERVO
Spektrum S660
Spektrum S660
Spektrum S660
SERVO GEAR MATERIAL
Plastic
Plastic
Plastic
MAX SERVO TORQUE @6v
6KGkg-cm / 84oz-in
6KGkg-cm / 84oz-in
6KGkg-cm / 84oz-in
MAX SERVO SPEED @6v
0.15sec
0.15sec
0.15sec
ARRMA Part Number
ARA3205T1
ARA3205ST1
ARA3205ST2
Vehicle Name
1/10 VORTEKS 2WD Stadium Truck RTR, Blue
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Orange
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Purple

Included

BATTERY INCLUDED
-
SPMX33007C3H 3300mAh 7C 8.4V Smart NiMH Hump IC3
SPMX33007C3H 3300mAh 7C 8.4V Smart NiMH Hump IC3
BATTERY CONNECTOR SUPPLIED
-
IC3
IC3
TOOLS INCLUDED
Multi Tool and Hex Wrenches (2.0, 2.5mm)
Multi Tool and Hex Wrenches (2.0, 2.5mm)
Multi Tool and Hex Wrenches (2.0, 2.5mm)

Required

RECOMMENDED LIPO BATTERY MINIMUM CONTINUOUS DISCHARGE RATE
25C 4000mAh
-
-
REQUIRED ITEMS
6 to 7-Cell NiMh, 2S Hardcase LiPo Battery, LiPo Charging Bag, Charger
-
-

Resources

ARA3205T1
1/10 VORTEKS 2WD Stadium Truck RTR, Blue
Product Page / Downloads
Exploded View (Interactive)
Standard Parts
Option Parts
ARA3205ST1
1/10 VORTEKS 2WD Stadium Truck RTR with Battery & Charger, Orange
Product Page / Downloads
Exploded View (Interactive)
Standard Parts
Option Parts
ARA3205ST2
Product Page / Downloads
Exploded View (Interactive)
Standard Parts
Option Parts
